Baby Oil Expeller
Technical Detal:
Our first basic & product: ‘Anand Oil Expeller Press’ is the most efficient, reliable & expeller available in the sub-continent. With vast experience of more than seven decades in serving oil mill industry, we have thorough knowledge of expelling oil most efficiently from the oil bearing seeds namely-cottonseed, ground nut (peanut), copra (coconut), mustard, canola (rapeseed), palm kernel, sunflower, castor, linseed, sesame, soybean, maize-germ, cashew nut-shell, walnut, sheanut, kardi, tumba, neem & other oil bearing seeds/nuts.
Feature
- High yield at low operating cost.
- High quality of both-oil & cakes.
- Heavy duty construction.
- Minimal initial investment with durable quality.
- Longer life of wearable parts.
- Best results on all oil bearing seeds, nuts & beans.
- Fast & easy replacement parts.
- Manufacturing & assembling with high precision.
- Crammar system for optimum feeding.
| Model | Production Capacity | Motor Requirement | |
|---|---|---|---|
| Baby | 1-2 ton | 7.5 HP | |
| Pre Press (24 hrs) | Full Press (in 24 hrs) | ||
| Young | - | 3-4 MT | 15-20 HP |
| Standard | 7-10 MT | 7-8 MT | 30-40 HP |
| Deluxe | 10-15 MT | 10-14 MT | 40-50 HP |
| Duplex | 20-25 MT | 15-20 MT | 50-75 HP |
| Super | 30-40 MT | 20-25 MT | 60-75 HP |
| Baby | Young | Standard | Deluxe | Duplex | Super | |
|---|---|---|---|---|---|---|
| Appx. Length | 72" | 90" | 105" | 110" | 120" | 135" |
| Appx. Width | 36" | 60" | 70" | 75" | 75" | 85" |
| Appx. Height | 66" | 75" | 110" | 110" | 110" | 125" |
| Appx. Weight | 1000 Kg | 2.3 Ton | 3.9 Ton | 4.2 Ton | 4.6-5.5 Ton | 6 Ton |
Note:
Dimensions are Approximate as per Standard fitments
Specification & Dimension are subject to change for betterment without any perior notification
Young Series Expeller
Standard Series Expeller
Delux Series Expeller
Duplex Series Expeller
